Fluke 717-3000G Pressure Calibrator

Model: 717-3000G | UPC: 095969327718

Downloads: datasheet manual

Fluke 717-3000G Pressure Calibrator

Model: 717-3000G

Pressure Calibrator 0 to 3000 PSI, (0 bar to 207 bar, 0 to 20684.27 kPa).

Your Price	$3450.99 CAD
Availability	2 to 3 Weeks
Quantity	Quantity

Traceable Calibration Certificate for your 717-3000G Pressure Calibrator

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIMPG4) for only $415.00 CAD

Traceable Calibration Certificate for your 717-3000G Pressure Calibrator

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIMPG4) for only $415.00 CAD

Recommended Accessories

Fluke C101 Hard Carrying Case

C101

Fluke TL81A Deluxe Electronic Test Lead Set

TL81A

Fluke TL80A Basic Electronic Test Lead Set

TL80A

Fluke 700LTP Low-pressure Test Pump

700LTP-1

Fluke 717-3000G Offers

Features

1/8 NPT female pressure fitting
Compatible with non-corrosive Gases and liquids
Zero, min, max, and hold functions
Calibrate P/I instruments with simultaneous pressure and current measurement
Error% calculation of mA measurements for quick pass-fail decisions
Long lasting battery life
Holster features test lead storage
Compatible with Toolpack magnetic hanging system
New switch test

Application Selection Guide


Model number	754	721/721Ex	719Pro	719	718	717	700G	3130	2700G	Dead-weight Testers
Application
Calibrating pressure transmitters (field)	●	●	Ideal	●	●	●		●
Calibrating pressure transmitters (bench)	●	●	●	●	●	●		Ideal		●
Calibrating HART Smart transmitters	Ideal
Documenting pressure transmitter calibrations	Ideal
Testing pressure switches in the field	Ideal	●	●	●	●	●		●
Testing pressure switches on the bench	●	●	●	●	●	●		Ideal
Documenting pressure switch tests	Ideal
Testing pressure switches with live (voltage) contacts	Ideal
Gas custody transfer computer tests	●	Ideal	●
Verifying process pressure gauges (field)	Ideal	●	●	●	●	●	●
Verifying process pressure gauges (bench)	●	●	●	●	●	●		●	●	Ideal
Logging pressure measurements	●						Ideal		●
Testing pressure devices using a reference gauge									Ideal
Hydrostatic vessel testing							Ideal
Leak testing (pressure measurement logging)	●						Ideal

Pressure Calibration Selection Guide

Fluke 717-3000G Specifications

Measurement Accuracy

Pressure

717 Series
Measure Pressure	(internal sensor)
Accuracy	0.05% full scale
Functions	Zero, Min, Max, Hold, Damp
	Note Gasses / liquids (non-corrosive)

Fluke 717 3000G
Range	0 to 3000 PSI, (0 bar to 207 bar, 0 to 20684.27 kPa)
Resolution	0.1 PSI, 0.01 bar, 1 kPa
Over Pressure	2 X full scale

Fluke 717 Series with Pressure Modules
Measure Pressure	(via pressure module connector using optional Pressure Modules)
Range	29 pressure modules, 0-1 inH20 to 10,000 PSI, 2.5 mbar to 700 bar ranges. Over pressure per pressure module specs
Resolution	Per pressure module specs
Accuracy	per pressure module specs
Functions	Zero, Min, Max, Hold, Damp

Current

Range:	0 to 24 mA (-25% to 125%)
Resolution	0.001 mA
Accuracy	0.015% + 2 counts

Specifications

Loop Power

Range	24 V dc
Accuracy	+/- 10%
	Note: Drive; 20 mA into 1000 ohms for battery >6.8V; 700 W for battery 5.8 to 6.8 V

Display

Clear 5 digit LCD

Environmental Specifications

Operating Temperature

-10 �C to 55 �C

Storage Temperature

-40 �C to 60 �C

Humidity (Without Condensation)

	95% (10 �C to 30 �C)
	75% (30 �C to 40 �C)
	45% (40 �C to 50 �C)
	35% (50 �C to 55 �C)

Operating Altitude

3,000 M max

Safety Specifications

Safety

CSA C22.2 No. 1010.1:1992

Mechanical & General Specifications

Size

201 mm L x 98 mm W x 52 mm (7.93in. L x 3.86in. W X 2.06in.)

Weight

22 oz, approximately 600G with holster

Warranty

3 years

Shock & Vibration

	Random, 2G, 5-500 Hz
	1m drop test

Battery type

Single 9V battery ANSI/NEDA 1604A or IEC 6LR619V alkaline

Click here for complete specifications on the Fluke 717-3000G

What's included with the Fluke 717-3000G

Protective Yellow Holster with Test Lead Storage
Instructions Sheet (14 Languages)
Test Leads and Alligator Clips
NIST Traceable Calibration Report and Data
Single 9V Alkaline Battery

datasheet for the Fluke 717-3000G Pressure Calibrator manual for the Fluke 717-3000G Pressure Calibrator
