Fluke 717-15G Pressure Calibrator 15 Psig

Model: 717-15G | UPC: 095969605625

Downloads: datasheet manual

Fluke 717-15G Pressure Calibrator 15 Psig

Model: 717-15G

Pressure switch test function captures set, reset and Deadband values of a pressure switch. Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power.

Your Price	$3254.99 CAD
Availability	2 to 3 Weeks
Quantity	Quantity

Traceable Calibration Certificate for your 717-15G Pressure Calibrator 15 Psig

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIPG4) for only $415.00 CAD

Traceable Calibration Certificate for your 717-15G Pressure Calibrator 15 Psig

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIPG4) for only $415.00 CAD

Recommended Accessories

Fluke TL220 Suregrip Industrial Test Lead Set

TL220

Fluke C101 Hard Carrying Case

C101

Fluke 80PK-27 SureGrip Industrial Surface Temperature Probe

80PK-27

Fluke TL81A Deluxe Electronic Test Lead Set

TL81A

Fluke 717 15G Fluke 717 Series Pressure Calibrators

The Fluke 717 Pressure Calibrators delivers outstanding performance, durability and reliability. These calibrators are compact, lightweight, and easy to carry. With a push button interface similar to the multifunction Fluke 740 Series Documenting Process Calibrators, the 717s are easy to use. They are EMI tolerant, dust and splash resistant, and feature a removable battery door for quick battery changes.
These calibrators come in 9 models measuring pressure up to 5000 psi/345 bar and are compatible with Fluke 700Pxx differential, gauge and absolute pressure modules to increase functionality.
Measure pressure, 0.05% of full scale with internal sensor up to 5000 PSI/345 bar sensor (5000G model)
Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power
Measure pressure to 10,000 psi/700 bar using one of 29 Fluke 700Pxx Pressure Modules
1/8 NPT female pressure fitting
Compatible with non-corrosive Gases and liquids
Select eleven different engineering units
Zero, min, max, and hold functions
Calibrate P/I instruments with simultaneous pressure and current measurement
Pressure switch test function captures set, reset and Deadband values of a pressure switch
Error% calculation of mA measurements for quick pass-fail decisions
Long lasting battery life
Holster Features test lead storage
Compatible with Toolpack magnetic hanging system
New switch test

Application Selection Guide


Model number	754	721/721Ex	719Pro	719	718	717	700G	3130	2700G	Dead-weight Testers
Application
Calibrating pressure transmitters (field)	●	●	Ideal	●	●	●		●
Calibrating pressure transmitters (bench)	●	●	●	●	●	●		Ideal		●
Calibrating HART Smart transmitters	Ideal
Documenting pressure transmitter calibrations	Ideal
Testing pressure switches in the field	Ideal	●	●	●	●	●		●
Testing pressure switches on the bench	●	●	●	●	●	●		Ideal
Documenting pressure switch tests	Ideal
Testing pressure switches with live (voltage) contacts	Ideal
Gas custody transfer computer tests	●	Ideal	●
Verifying process pressure gauges (field)	Ideal	●	●	●	●	●	●
Verifying process pressure gauges (bench)	●	●	●	●	●	●		●	●	Ideal
Logging pressure measurements	●						Ideal		●
Testing pressure devices using a reference gauge									Ideal
Hydrostatic vessel testing							Ideal
Leak testing (pressure measurement logging)	●						Ideal

Pressure Calibration Selection Guide

Fluke 717-15G Specifications

Range	29 pressure modules, 0 – 1 in H20 to 10,000 PSI, 2.5 mbar to 700 bar ranges over pressure per pressure module specs
Resolution	Per pressure module specs
Accuracy	0.025 % of full span, per pressure module specs
Functions	Zero, Min, Max, Hold, Damp, error calculation
Note	Media compatibility per pressure module specs

Click here for complete specifications on the Fluke 717-15G

What's included with the Fluke 717-15G

Protective Yellow Holster with Test Lead Storage
Instructions Sheet
Single 9V Alkaline Battery
Test Leads and Alligator Clips
NIST Traceable Calibration Report and Data

Brochure Pressure Calibration Selection Guide datasheet for the Fluke 717-15G Pressure Calibrator 15 Psig manual for the Fluke 717-15G Pressure Calibrator 15 Psig
