Get clear, accurate focus with laser speed on your designated target with the LaserSharp™ Auto Focus. Use a built-in laser distance meter to calculate and display the distance to your designated target on the camera screen with the touch of a button.
Get clear, accurate focus with laser speed on your designated target with the LaserSharp™ Auto Focus. Use a built-in laser distance meter to calculate and display the distance to your designated target on the camera screen with the touch of a button.
Discontinued!
This product has been discontinued and is no longer available.
This is the direct replacement:
The Fluke PRO series cameras introduce a leading-edge visual infrared experience. These thermal imagers feature our smartest, most intuitive user interface and increased thermal sensitivity to capture the smallest differences. Equipped with the latest technology for on-screen clarity and lens compatibility to capture targets tiny-to-large, our best-selling cameras just got better.
Features
| Infrared Resolution | 240 x 180 (43,200 Pixels) |
| IFOV with Standard Lens (Spatial Resolution) | 1.75 mRad, D:S 565:1 |
| Field of View | 24° x 17° |
| Minimum Focus Distance | 15 cm (6") |
| Thermal Sensitivity (NETD) | ≤0.04°C @ 30°C Target Temperature (40 mK) |
| Frame Rate | 60 Hz or 9 Hz Versions |
| Battery Life | 3 to 4 hours per battery (actual life varies depending on settings and usage) |
| Temperature Measurement Range (Not Calibrated Below -10°C) | -20 to 650°C (-4 to 1202°F) |
| Operating Temperature | -10 to 50°C (14 to 122°F) |
| Storage Temperature | -20 to 50°C (-4 to 122°F) Without Batteries |
| Dimensions | 27.7 x 12.2 x 16.7 cm (10.9 x 4.8 x 6.5") |
| Weight (Battery Included) | 1.04 kg (2.3 lb) |
