Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C

Model: 6102-156 | UPC: 095969127615

Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C-


Downloads: datasheet manual

Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C

Model: 6102-156

Worlds smallest portable calibration bath that can be transported with fluid in them. This model uses a fluid medium which eliminates the problems of fit and immersion issues.

Worlds smallest portable calibration bath that can be transported with fluid in them. This model uses a fluid medium which eliminates the problems of fit and immersion issues.

This product has been discontinued. Click here for the replacement model(s).


Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C Offers

Features

  • World's smallest portable calibration baths can be transported with the fluid in them
  • Stable to ±0.03°C or better, depending on the fluid you use
  • Uniformity is ±0.02°C or better for low uncertainties using a reference thermometer
  • Display accuracy has been improved to ±0.25°C for quick calibrations without a reference thermometer
  • With a 48mm (1.9") diameter, 140mm (5.5") deep tank, user can calibrate any type of sensor including short, square, or odd-shaped sensors
  • Problems of fit and immersion are virtually eliminated by using a fluid medium rather than a dry-block calibrator
  • Micro-Baths are perfect for liquid-in-glass and bimetal thermometers
  • All models have RS-232 ports, come with Interface-it software, and can be used with MET/TEMP II software
  • Also included are contacts to calibrate a thermal switch, eight set-point memory storage, ramp-rate adjust, and over-temperature safety cutout
  • Cold Micro-Baths are CFC-free as well as compressor-free

Applications

Ideal for the following applications: Laboratory, Education, R&D, Calibration Labs, Field Calibration

Fluke 6102-156 Specifications

Temperature Range 35 to 200°C (95 to 392°F)
Stability ±0.02°C @ 100°C; ±0.03°C @ 200°C (oil 5013)
Accuracy ±0.25°C
Uniformity ±0.02°C
Resolution 0.01°C/°F
Heating Time 25 to 200°C: 40 minutes
Cooling Time 200 to 100°C: 35 minutes
Fluid Volume 0.75L
Well Size 2.5" dia. x 5.5" deep (64 x 139 mm) Access opening is 1.9" (48 mm) dia.
Click here for complete specifications on the Fluke 6102-156

What's included with the Fluke 6102-156

  • Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C
  • Click on a category to view a selection of compatible accessories with the Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C.

    Fluke 2083 Tank Extension Adapter, 3" 2083
    Tank Extension Adapter for the 6102, 7102 and 7103 Liquid Bath Calibrators.




    Fluke 9310 Carrying Case for the Fluke 6102 9310
    Carrying case for the 6102 Liquid Bath Calibrator.




    Fluke 2082-M Spare Tank Lid for the Fluke 6102 2082-M
    Spare Tank Lid for the 6102 Liquid Bath Calibrator.




    Fluke 5010-1L Silicone Oil, Type 200.50, 1L, -40 to 130°C 5010-1L
    Silicone oil for the 6102, 7102 and 7103 Liquid Bath Calibrators.




    Fluke 5013-1L Silicone Oil, Type 200.20, 1L, 10 to 230°C 5013-1L
    Silicone oil for the Fluke 6102, 7102 and 7103 Liquid Bath Calibrators.




    Customer Reviews for the Fluke 6102-156

    Ask a question about Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C

    Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C Offers

    Features

    • World's smallest portable calibration baths can be transported with the fluid in them
    • Stable to ±0.03°C or better, depending on the fluid you use
    • Uniformity is ±0.02°C or better for low uncertainties using a reference thermometer
    • Display accuracy has been improved to ±0.25°C for quick calibrations without a reference thermometer
    • With a 48mm (1.9") diameter, 140mm (5.5") deep tank, user can calibrate any type of sensor including short, square, or odd-shaped sensors
    • Problems of fit and immersion are virtually eliminated by using a fluid medium rather than a dry-block calibrator
    • Micro-Baths are perfect for liquid-in-glass and bimetal thermometers
    • All models have RS-232 ports, come with Interface-it software, and can be used with MET/TEMP II software
    • Also included are contacts to calibrate a thermal switch, eight set-point memory storage, ramp-rate adjust, and over-temperature safety cutout
    • Cold Micro-Baths are CFC-free as well as compressor-free

    Applications

    Ideal for the following applications: Laboratory, Education, R&D, Calibration Labs, Field Calibration

    Fluke 6102-156 Specifications

    Temperature Range 35 to 200°C (95 to 392°F)
    Stability ±0.02°C @ 100°C; ±0.03°C @ 200°C (oil 5013)
    Accuracy ±0.25°C
    Uniformity ±0.02°C
    Resolution 0.01°C/°F
    Heating Time 25 to 200°C: 40 minutes
    Cooling Time 200 to 100°C: 35 minutes
    Fluid Volume 0.75L
    Well Size 2.5" dia. x 5.5" deep (64 x 139 mm) Access opening is 1.9" (48 mm) dia.
    Click here for complete specifications on the Fluke 6102-156

    What's included with the Fluke 6102-156

  • Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C
  • Click on a category to view a selection of compatible accessories with the Fluke 6102-156 Liquid Bath Calibrator, 35 to 200°C.

    Fluke 2083 Tank Extension Adapter, 3" 2083
    Tank Extension Adapter for the 6102, 7102 and 7103 Liquid Bath Calibrators.




    Fluke 9310 Carrying Case for the Fluke 6102 9310
    Carrying case for the 6102 Liquid Bath Calibrator.




    Fluke 2082-M Spare Tank Lid for the Fluke 6102 2082-M
    Spare Tank Lid for the 6102 Liquid Bath Calibrator.




    Fluke 5010-1L Silicone Oil, Type 200.50, 1L, -40 to 130°C 5010-1L
    Silicone oil for the 6102, 7102 and 7103 Liquid Bath Calibrators.




    Fluke 5013-1L Silicone Oil, Type 200.20, 1L, 10 to 230°C 5013-1L
    Silicone oil for the Fluke 6102, 7102 and 7103 Liquid Bath Calibrators.
