Fluke 190-202 ScopeMeter Oscilloscope, 2 Channel, 200 MHz

Model: 190-202/AM | UPC: 095969601573

Fluke 190-202 ScopeMeter Oscilloscope, 2 Channel, 200 MHz-


Downloads: datasheet manual

Fluke 190-202 ScopeMeter Oscilloscope, 2 Channel, 200 MHz

Model: 190-202/AM

High performance handheld scopes built tough. 2.5 GS/s sampling rate, 200MHz bandwidth with 2 input channels and DMM for industrial process control, automation or electronic applications.

High performance handheld scopes built tough. 2.5 GS/s sampling rate, 200MHz bandwidth with 2 input channels and DMM for industrial process control, automation or electronic applications.

Your Price $6197.00 CAD
Availability 2 to 3 Weeks
Quantity

Add In-House ISO Certified Calibration to your 190-202/AM

Add In-House ISO Certified Calibration to your 190-202/AM


Fluke 190-202/AM Offers

Simplify electrical signal analysis and diagnose equipment failures in the field with the Fluke 190-202. The portable oscilloscope offers the same performance as a bench scope with feature–rich capabilities to tackle just about any troubleshooting task. Designed for plant maintenance engineers and technicians, the 190 ScopeMeter® Series goes into harsh and dirty industrial conditions to test everything from microelectronics to power electronics applications. The Fluke 190-202 two-channel portable oscilloscope features a CAT III 1000V/CAT IV 600V safety rating and is IP-51 rated to withstand harsh environments. Get unprecedented ease-of-use with Connect-and-View™ triggering to capture and analyze waveforms hands free. With 200MHz bandwidth and real-time sampling rates up to 2.5 GS/sec, you can quickly and easily capture noise and other disturbances to quickly make sense of your signals and eliminate the tedium of troubleshooting.

Features

  • 2 independent floating isolated inputs for making differential measurements
  • Flexibility and convenience of an integrated 5000 count digital multimeter
  • Increased resolution and work load coverage: 200MHz bandwidth and 2.5 GS/sec high-speed sampling
  • CAT III 1000 V/CAT IV 600 V safety rated for high voltage environments
  • Connect-and-View™ for intelligent, automatic triggering on fast, slow and even complex signals
  • ScopeRecord™ Roll mode captures low frequency signal anomalies over minutes, hours, or days
  • TrendPlot™ paperless recorder mode trends meter measurements over days and weeks to identify signal changes
  • Automatic capture and replay of last 100 screens
  • Isolated USB host port for memory devices and PC connectivity
  • Up to 7 hours of standard battery operation and easy-access battery door for quick battery swaps in the field

Applications

  • Automation & Process Control
  • Industrial
  • Maintenance & Repair
  • Motor Drive & Control
  • Test & Measurement

Fluke 190-202/AM Specifications

Number of Channels 2
Bandwidth 200MHz
Rise Time 1.7ns
Number of Scope Inputs 2 Input Channels plus External Trigger
Input Coupling AC or DC, with ground level indicator
Input Sensitivity 2 mV/div to 100 V/div, plus variable attenuation
Bandwidth Limitier User selectable: 20 kHz, 20 MHz or full bandwidth
Normal/Invert/Variable On each input channel, switched separately
Input Voltage CAT III 1000 V/CAT IV 600 V rated, see General Specifications for further details
Vertical resolution 8 Bit
Click here for complete specifications on the Fluke 190-202/AM

What's included with the Fluke 190-202/AM

  • ScopeMeter Oscilloscope
  • BC190 Battery
  • Charger/Mains Adapter
  • Li-ion Battery Pack
  • VPS410 Voltage Probe Sets
  • TL175 Test Leads
  • Hang Strap
  • Hand Strip
  • Multi-language user's manual on CD-ROM and FlukeView demo package

Fluke ScopeMeter 190 Series II Portable Oscilloscopes Demo Circuit: Overview


This video showcases the main features and functions of these portable oscilloscopes. Additionally, the user can perform timing or amplitude related measurements on three phases or three-axis control systems, or compare and contrast multiple test points in a circuit under test.

How To Use Instant Replay On a Fluke 190 ScopeMeter Oscilloscope


In this video, the user learns how to capture random events using triggering and show the results in instant replay. The scope meter oscilloscope can quickly and easily capture disturbances to make sense of your signals and eliminate the tedium of troubleshooting.

How To Create and Recall Waveforms Using the Fluke 190 Series Portable Oscilloscope


This video will serve as a step by step tutorial on how to set up waveforms with the oscilloscope, and how to return settings to factory default. Additionally, this instrument offers the same performance as a bench scope with feature-rich capabilities to tackle just about any troubleshooting task.

How to Synchronize a Fluke 190 Series Portable Oscilloscope with Basic Triggers


This video breaks down the process of synchronizing your portable oscilloscope with triggers. The TRIGGER function allows the user to synchronize their scopemeter with the signal the oscilloscope is connected to and display waveforms on your instrument.

How To Startup and Reset Settings on the Fluke ScopeMeter Portable Oscilloscope


This video is a walkthrough on how to power up and perform a reset with the scopemeter. Ideal for plant maintenance engineers and technicians, this instrument goes into harsh and dirty industrial conditions to test everything from microelectronics to power electronics applications.

How To Transfer Data From a Fluke ScopeMeter Portable Oscilloscope onto a USB Drive


This video is a tutorial on how to transfer data from a fluke scope meter directly onto a USB drive. The oscilloscope comes with an isolated USB host port for direct data storage from a USB to a computer.

How To Use the TrendPlot® Function on the Fluke ScopeMeter Portable Oscilloscope


In this video, the user learns how to set up the TrendPlot function to find intermittent faults. The function plots minimum and maximum peak values for up to 22 days, in any combination of voltages, amps, temperature, frequency, and phase for all four inputs.

Click on a category to view a selection of compatible accessories with the Fluke 190-202 ScopeMeter Oscilloscope, 2 Channel, 200 MHz.





Fluke C290 Hard Shell Protective Carrying Case for the Fluke 190-II Series C290
Includes pockets to store probes and leads.








Fluke TL175 TwistGuard Test Leads Set TL175
By simply twisting the test lead the user can change the exposed probe tip length from 19 mm to 4 mm (0.75 inch to 0.16 inch).




Fluke SW90W FlukeView ScopeMeter Software SW90W
Documents, archives, and analyzes slow moving signals and related events. For use with 120B Series ScopeMeters.




Fluke SCC290 ScopeMeter Software & Carrying Case Kit SCC290
Kit comes with FlukeView ScopeMeter software and the Fluke C290 carrying case.




Fluke EBC290 External Battery Charger EBC290
External battery charger for Li-ion batteries for 190B and 120B Series ScopeMeters and power quality analyzers.




Fluke BP290 Li-Ion Battery Pack BP290
For Fluke 43X power quality analyzers and 190-series ScopeMeters.
